MicroMax, as a manufacturer of industrial computers, takes a customized approach to each
client. Our engineering group can design M-Max systems to fit customer-specific technical
MicroMax’s in-house off-the-shelf solutions. All models are expandable due to stackable architecture aided by proprietary design features of M-Max computers. Most systems are equipped with proprietary technology which provides heat dissipation from electronic boards and components exposed to high shock and vibration
M-Max Systems for all major kinds of transport. Adapted to harsh environments and
are able to withstand shock and vibration
M-Max rackmount systems. Their distinctive features are improved reliability and extended time between service need
M-Max systems for railroad applications, either onboard or stationary, are designed to withstand harsh environments
M-Max aircraft systems are designed considering weight limitations and need for ruggedness and reliability
M-Max systems for marine applications are designed with special attention to water and salt fog resistance
M-Max vehicle systems are designed for enhanced shock and vibration resistance and dust protection
Standard solutions don’t always fit needs, and each industry may have its own special computing requirements. MicroMax supports each client’s needs by taking a customized approach to optimize each of its industrial computers. Our M-Max systems are excellent for harsh scenarios such as train or marine use, limited-sheltered outdoor applications in heat and cold, and tough industrial environments with dust, dirt, and other contaminants being a factor. Some of our many designs are shown below.
The M-Max 910 CU high-performance rugged industrial computer provides reliable operation in tough environments. The fully-ruggedized ATR-type aluminum chassis is fanless and uses natural convection and conduction cooling in accordance with MIL-STD-810 standards. COTS technology components allow configuring the M-Max 910 family to comply with a wide variety of airborne, marine and ground vehicle applications.
Delivering outstanding performance comparable to high-end desktop systems, it also features extended graphics capabilities, providing up to 6x HDMI outputs.
The M-Max SW208/AC is a ruggedized 8-Port Gigabit Ethernet Layer 2+ Managed Switch providing reliable operation in tough environments including transportation (ground, rail, air and marine), agriculture, and mining and processing. It accepts a wide power supply voltage input, and is tested and guaranteed over temperature range of −40 to +75°C. Its rugged enclosure is designed according to VITA75 footprint. The SW208/AC has eight 10/100/1000 Mbps copper twisted pair ports. Support for control and management is through web interface, and host processor access through a Command Line Interface (CLI).
Rugged high performance computer for tough environments. The M-Max 871 EP4 enclosure is designed according to the VITA 75 footprint and can be mounted on different vehicle types. Lightweight compact sealed case with patented fanless heat dissipation resists contamination and humidity. Providing shock and vibration protection, the M-Max 871 EP4 can operate under extreme temperatures (-40 to +60 °C). Computing power is in the high-end desktop class. The embedded power supply complies with MIL-STD-704F specification.
MicroMax, as a manufacturer of industrial computers, takes a customized approach to each client. Our engineering group can design M-Max systems to fit customer-specific technical requirements.
